500W Laser Cleaning Machine
Quick detail
1. Low power consumption;
2. No need to sand grit or chemical, only 110/220V electricity;
3. No damage to the substrate;
4. Low noise;
5. Accurate cleaning effects;
6. No maintenance requirements.
7. Esay operation;
8. Fast investment recovery;
Specification List
| Items | Parameters |
| Cleaning Power | 50W | 100W | 200W | 500W |
| Current Consumption | Pout = Ponm / 5A | Pout = Ponm / 5A | Pout = Ponm / 5A | Pout = Ponm / 25A |
| Max. Power | 400W | 600W | 900W | 6.5KW |
| Power Voltage | AC 110/220V | AC 110/220V | AC 110/220V | AC 110/220V |
| Cooling Method | Air Cooling | Air Cooling | Air Cooling | Water Cooling |
| Laser Class | Level 4 | Level 4 | Level 4 | Level 4 |
| Pulse Energy | 1mJ | 1.5mJ | 8mJ | 30mJ |
| Fiber Optical Cable | 5m(Customizable) | 5m(Customizable) | 5m(Customizable) | 7m(Customizable) |
| Laser Wavelength | 1064nm | 1064nm | 1064nm | 1064nm |
| Scan Width | 1-120mm | 1-120mm | 1-120mm | 1-160mm |
| Preheat Time | 10-30s | 10-30s | 10-30s | 10-30s |
| Working Condition | A flat place without vibration and impact | A flat place without vibration and impact | A flat place without vibration and impact | A flat place without vibration and impact |
| Working Temperature | 0-60 ℃ | 0-60 ℃ | 0-60 ℃ | 0-60 ℃ |
| Storage Temperature | -10~+60℃ | -10~+60℃ | -10~+60℃ | -10~+60℃ |
| Machine size | L462 x W 260 x H562 (855mm with pull rod) | L647 x W 440 x H859mm | L647 x W 440 x H859mm | L1100 x W 840 x H1150mm |
| Net Weight | 32Kgs | 70Kgs | 70Kgs | 250Kgs |
Application
(1).Metal surface rust removal
(2).Paint cleaning
(3).Oil stain, contaminant cleaning
(4).Coating surface cleaning
(5)Welding/Coating surface pre-treatment.
(6).Stone figure surface dust & attachment cleaning.
(7).Plastic mold residues cleaning
Pre-welding treatment: In the welding process, surface impurities need to be cleaned up before welding. After welding, there will be a large area of oxidation, forming a layer of weld. The traditional method is usually mechanical grinding or erasing with chemical reagents. The traditional cleaning effect is more polluted, and the poor cleaning effect will cause greater damage to the substrate and it is difficult to clean the corners.
Laser cleaning is fast enough to perform pre-weld cleaning and efficient cleaning of the weld bead. Fast cleaning, no consumables, no maintenance, no pollution, low cost.
Features
(1). First high power fiber laser cleaning machine in China.
(2). Non-contact cleaning, no damage to the workpiece
(3). Precision positioning, selective cleaning, desired cleaning area can be applied to the workpiece
(4). No need chemical detergent, no consumable. Safe & environment-friendly.
(5). Easy to operate, Either portable or equipped with a robot for automatic cleaning.
(6). High cleaning efficiency, time-saving.
(7). Stable laser cleaning system, free maintenance.
How Fiber Laser Cleaning Works
Laser cleaning is one of the more modern versions of the cleaning process and has rapidly replaced more traditional methods such as dry-ice blasting or media blasting due to the numerous benefits that it provides.
It offers these benefits as it works in a significantly different way to the processes that have preceded it. Furthermore, using a fiber laser as the medium also works in a much different way to other types of cleaning methods. We have explored this in more detail below and explained why laser-based cleaning is the most efficient, safe and cost-effective cleaning solution on the market.
