Intelligent Laser Cleaning Machine Oil Stain Painting Handheld Laser Cleaner
| Item | L/N | Characteristics | Test Conditions | Min. | Typical | Max. | Unit |
| Electrical Characteristics | 1 | Power Voltage | 220 | 210 | 220 | 230 | AC |
| 2 | Maximum current loss | Pout=Pnom | 4 | 5 | 6 | A |
| 3 | Total Power | 900 | 890 | 900 | 910 | W |
| 4 | Fiber Cable | 5 | 5 | 5 | 10 | M |
| General Characteristics | 1 | Working temperature range | 0 | / | 60 | ℃ |
| 2 | Storage temperature | -10 | / | 60 | ℃ |
| 3 | Laser power | 200 | W |
| 4 | Peak power | >30KW | KW |
| 5 | Cooling method | Air Cooling | |
| 6 | Laser level | 4 Class | |
| 7 | Pulse energy | 10mJ | mJ |
| 8 | Laser wavelength | 1064 | nm |
| 9 | Preheat time | Reach to start operation | 0 | s |
| Achieve complete stability | 10 |
| 10 | Humidity | 10 | / | 95 | % |
| 11 | Laser machine size | L647*W440*H859 | mm |
| 12 | Weight | 70 | kg |
| Apply to | 1. Metal surface rust removal |
| 2. Paint cleaning |
| 3. Oil stain, contaminant cleaning |
| 4. Coating surface cleaning |
| 5. Welding/Coating surface pre-treatment |
| 6. Stone figure surface dust & attachment cleaning |
| 7. Plastic mold residues cleaning |
| Industries | 1. Mould |
| 2. High-end machine tools |
| 3. Ship |
| 4. Vehicle parts |
| 5. Rubber tire |
| 6. Environmental protection industry |
| 7. Printing Industry |
| 8. Road track |
| 9. Microelectronics |
Product Description
A laser cleaning machine is easy to clean rust and remove paint and oil. Easy to operate, turn on the power, open the device, then you can begin no chemical reagents, no media, dust-free, anhydrous cleaning, autofocus, fit surface cleaning, cleaning the surface cleanliness advantages, to clear the surface resin, Oil, dirt, dirt, rust, coating, coating, paint.
Application Field
| A Metal surface cleaning |
| B Removal paint of metal surface |
| C stains cleaning on the surface |
| D Surface coating cleaning |
| E Pre-treatment of welding surface cleaning |
| F Stone surface cleaning |
| G Rubber mold residue cleaning |
Advantages of fiber laser surface preparation
There are many advantages of a fiber laser-based approach to surface preparation, we have listed some of the advantages below:
· Chemical-free – no chemicals are used with a laser-based approach. Chemicals introduce their own risks such as corrosion, damage to substrate materials, discoloration, toxicity, waste products
· Contactless approach – there is no need for contact to be made with the material when the surface is being prepared. This reduces risk to the material and the user, the only contact is remote via the laser beam
· Minimal residue – apart from a little dust (which might not even arise), there is no residue with fiber laser preparation treatment whereas traditional approaches can have waste by-products, such as chemical slurries
· No corrosion – relating to the use of chemicals is corrosion. With a fiber laser, there is a zero % chance risk of any form of corrosion damage to the material lying underneath the surface
· No tooling – apart from the laser itself there is no tooling required (e.g. power tools, blasting equipment, etc.)
· Precision and control – no other method offers such precision and control. The laser operator controls the exact depth and surface contaminants are carefully removed layer by layer
· Speed – Lasers prepare surfaces very fast, in a time-pressured world this is an important benefit, especially when compared to manual methods, which are time-consuming and therefore expensive on labor.
After-sales Service
1. 12 languages 24 hours Quick Feedback;
2. "Training Video", "Instruction Book", and "Operation Manual" will be offered;
3. Brochures for simple trouble-shootings of the machine is available;
4. Plenty of technical support online is available;
5. Quick Back-up Parts Available & Technical Assistance;
6. Free training service is available.
